The Fox’s frame is made with 7075 alloy tubes, which is lighter than 2024. The weight of the wing is reduced for almost 1 kg!
The A-frame is made with Finsterwalder uprights and fittings, the same as Discus A-frame.
Fox has got new sail design: in additional to general sail refinements, the rear edge is changed to comfortable Airborne batten tips. The composite X-lam cloth APEN 6 is now available as sail option for those, who is looking for a splendid view.
The cross-beam and rear upper wire is tensioned in one movement.
The Fox hang glider has been certified at DHV!
In the result we have developed modern wing for the beginners, which became lighter and easier to assemble and kept good flying characteristics of its predecessor:
Besides the standard version of Fox (Fox А) there are two modifications (versions):
Sail area, m2 | 16,2 |
Wing span, m | 9,6 |
Aspect ratio | 5,7 |
Nose angle, ° | 120° |
Weight, kg | 25,2 |
Brakedown length, m | 5.7/3.8/2.5 |
Hook-in pilot weight, kg | 60-114 |
Top Batten Number | 15 |
Double Sail | 30% |
Min. airspeed, km/h | 25 |
Va, km/h (mph), | 70 (44) |
VNE, km/h (mph), | 81 (50) |
Best glide ratio | 9 |
DHV Certificate | № 01-0457-10 |
